TG-2 thru TG-83
BEECHCRAFT
|
INDEX:
Go to: Windshields Go to: Pilot and Vent Windows Go to: Door Window Go to: Center / Escape Hatch Windows Go to: 3rd Windows Go to: Landing light lens --------------------------- OTHER PAGES: Go to: Miscellaneous Beech Parts Go to: Windshield and Window Cleaners Go to: Special Drills for Plastic --------------------------- Special Instructions Go to: Instructions for Stc'd Pilot and Door Window (part numbers 2048, 2049, (2237 is similar)) Go to: Instructions for Stc'd Door Window (part number 2222) Go to: Instructions for Stc'd Door Window (part number 2221) Go to: Instructions for Windshields and Windows that will be using the original Beechcraft Frame |
Turbo Baron
|
||||
|
|
Details | Thickness | Clear (W-) |
Green (W/T-) |
Gray (W/G-) |
SC Green (SC-W/T-) |
SC Gray (SC-W/G-) |
Part Number
(G.L.A.P.) |
|
| USE Original Frame | OEM Thickness | Details | .250" | $1,390.38 | $1,668.46 | $1,668.46 | $2,252.42 | $2,252.42 | 2075 |
| ELIMINATES FRAME | STC'd 1pc. | Details | .250" | $1,374.76 | $1,649.71 | $1,649.71 | $2,227.11 | $2,227.11 |
2050 |
|
Screw Kit For Part Number 2050 |
$60.00 |
||||||||
| (uses original Beech frame and hardware) | Details | Thickness | Clear (W-) |
Green (W/T-) |
Gray (W/G-) |
SC Green (SC-W/T-) |
SC Gray (SC-W/G-) |
Part Number
(G.L.A.P.) |
|
| Pilot | Details | .125" | $283.15 | $339.78 | $339.78 | $458.71 | $458.71 | 2035-LH | |
| Vent | Details | .125" | $ 91.78 | $110.14 | $110.14 | $148.68 | $148.68 | 2218 | |
| Pilot | Thick | Details | .187" | $322.21 | $386.65 | $386.65 | $521.98 | $521.98 | 2035-187-LH |
| Vent | Thick | Details | .187" | $ 97.64 | $117.17 | $117.17 | $158.18 | $158.18 | 2218-187 |
| Pilot | MILLED EDGE | .250" | $656.13 | $787.36 | $787.36 | $1,062.94 | $1,062.94 | 2584 | |
| Vent | MILLED EDGE | .250" | $259.72 | $311.66 | $311.66 | $420.75 | $420.75 | 2585 | |
| Pilot and Vent Window Assemblies | |||||||||
| STC ELIMINATES FRAME | PLASTIC Hardware |
.250" |
$1,090.89 | $1,242.92 | $1,242.92 | $1,577.60 | $1,577.60 |
2237 |
|
|
PLASTIC Hinges & latch only, like the ones used on 2237 |
$250.00 |
||||||||
|
Screw Kit for Part Numbers 2048 & 2237 |
$50.00 |
||||||||
| Details | Thickness | Clear (W-) |
Green (W/T-) |
Gray (W/G-) |
SC Green (SC-W/T-) |
SC Gray (SC-W/G-) |
Part Number
(G.L.A.P.) |
||
| USE Original Frame | OEM Thickness | Details | .125" | $283.15 | $339.78 | $339.78 | $458.71 | $458.71 | 2035-RH |
| Thick | Details | .187" | $322.21 | $386.65 | $386.65 | $521.98 | $521.98 | 2035-187-RH | |
| Extra Thick (Milled Edge) |
.250" milled edge |
$540.92 | $649.10 | $649.10 | $876.29 | $876.29 | 2190 | ||
| ELIMINATES FRAME | (STC'd) Extra Thick | Details | .250" | $367.12 | $440.55 | $440.55 | $594.74 | $594.74 | 2049 |
| Stainless Screw Kit for Part Numbers 2049 | $50.00 | ||||||||
| Door and Vent window Assembled with Vent: | |||||||||
|
USE Original Frame |
PLASTIC Hardware | Details |
.250" milled edge |
$1,196.01 | $1,311.01 | $1,311.01 | $1,567.92 | $1,567.92 | 2254 |
|
STC ELIMINATES FRAME |
PLASTIC Hardware | Details | .250" | $1,061.62 | $1,176.62 | $1,176.62 | $1,433.53 | $1,433.53 | 2222 |
| PLASTIC Hinges & latch only, like the ones used on 2222 & 2254 | Details |
|
$250.00 |
||||||
|
Screw Kit for Part Numbers 2221 & 2222 |
$50.00 |
||||||||
| Opening Style
(Emergency Exit) USE Original Frame |
Details | Thickness | Clear (W-) |
Green (W/T-) |
Gray (W/G-) |
Dark Gray (W/XT-) |
SC Green (SC-W/T-) |
SC Gray (SC-W/G-) |
Part Number
(G.L.A.P.) |
|
| Standard | Right
or Left |
Details | .125" | $218.71 | $262.45 | $262.45 | $262.45 | $354.31 | $354.31 |
2041-2-RH or |
| Beech Option | Right or Left |
Details |
.250" milled edge |
$496.01 | $595.21 | $595.21 | $595.21 | $803.53 | $803.53 | 2187-RH
or 2187-LH |
| Details | Thickness | Clear (W-) |
Green (W/T-) |
Gray (W/G-) |
Dark Gray (W/XT-) |
SC Green (SC-W/T-) |
SC Gray (SC-W/G-) |
Part Number
(G.L.A.P.) |
||
| Standard | Right
or Left |
Details | .125" | $216.76 | $260.11 | $260.11 | $260.11 | $351.15 | $351.15 | 2047-RH
or 2047-LH |
| Beech Option | Right or Left |
Details | .250" | $308.54 | $370.25 | $370.25 | $370.25 | $499.83 | $499.83 | 2197-RH or 2197-LH |
| With Photo Port | Right
or Left |
Details | .250" | $1,003.03 | $1,106.32 | $1,106.32 | --- | $1,338.63 | $1,338.63 | 2780-RH or 2780-LH |
| (leading edge of wing) | Details | Thickness | Clear
(W-) |
Part Number
(G.L.A.P.) |
| Right or Left |
Details |
.080" |
$103.50 | 2194-RH or 2194-LH |
